Hitch Mounted Utility Cargo Carrier

The UCC500 hitch mounted utility cargo carrier is specially designed for carrying lawn mower, power equipment, snow throwers and other pieces of small equipment. This 500 lb capacity carrier includes an integrated 42-1/2"L by 30"W loading ramp which folds down for easily loading and then folds up and locks in place after use. Large 10,237 sq inch carrying basket has plenty of storage. This carrier easily installs into any Class III or IV 2" hitch receiver. Made from heavy duty steel with a smooth black powder coat finish for protection. The mesh basket surface allows dirt and moisture to pass through the carrier.

  • Made from durable black heavy duty powder coated steel
  • Great for carrying lawn mowers, snow blowers, and other utility equipment
  • 10,237 square inch capacity basket - 30"W x 45-1/2"L x 7-1/2"H (usable size)
  • Includes 42-1/2" Lx 30" W loading ramp
  • Mesh basket is lighter weight and provides great drainage
  • 5" clearance from hitch pin to back of carrier
  • Numerous tie down points - straps sold separately
$189.99
UCC500
$45.00
In Stock. Ships within 24 hrs.
1 Year Warranty Curt Trailer Configurator

Summary

Hitch mounted carrier designed for 2" Class III/IV vehicle hitch receivers. Holds up to 500 lbs of gear and equipment. Great for lawn mowers, utility equipment, snow throwers, and more! Includes a 1 year Manufacturer's warranty.

Detail

The UCC500 Hitch Cargo Basket is designed to haul extra gear and equipment using a 2" Class III/IV vehicle hitch receiver. Great for hauling a snow blower, lawn mower, and other utility equipment without taking up space inside the vehicle. An integrated 42-1/2" x 30" loading ramp allows heavier equipment weighing up to 500 lbs to easily be placed into the basket for transport. Once the cargo basket is loaded, the loading ramp locks in the upright position with (2) pins. The 1" square tube basket frame provides plenty of options for securing tie-down straps or cargo nets with hook ends. A mesh surface basket and loading ramp allows debris and water to pass through, and reduces the overall weight of the cargo carrier. The UCC500 hitch mounted carrier is made with heavy duty steel construction with a smooth black powder-coat finish. Some assembly is required for installation. Hitch pin is sold separately.

To install the cargo basket, just insert the carrier's main tube into your vehicle's hitch receiver and secure using a hitch pin. Load up your cargo and you're ready to go! Cargo nets, optional locking hitch pins, and other accessories are available for added versatility of your brand new cargo basket! Includes a 1 year warranty! Please Note: Exceeding your vehicle's hitch rating may result in failure of the device and personal injury.

Class III or IV (2")
Steel
UCC500 Hitch Cargo Basket - Hitch mounted carrier for 2" Class III/IV vehicle hitch receivers
48"
32"
7-1/2"
45-1/2"
30"
7-1/2"
42-1/2" x 30"
5" Hitch Pin to Carrier
Class III or Class IV
76 lbs
NOT recommended for any tow-behind trailers including 5th wheel trailers & camping trailers due to excessive bouncing of the vehicle's suspension
500 lbs
Basket with Ramp

Product Features

  • Hauls extra gear and equipment with a 2" Class III/IV hitch receiver
  • Great for snow blowers, lawn mowers and utility equipment
  • 5" Clearance from vehicle hitch pin to carrier basket
  • Integrated 42-1/2" x 30" loading ramp
  • Locking pins hold ramp in the upright position
  • Mesh basket and loading ramp surface
  • Large 30" x 45-1/2" x 7-1/2" usable basket area
  • 1" Square tube basket frame
  • Some assembly is required
  • Plenty of areas for tie-down points
  • Heavy duty steel construction
  • Black powder-coat finish
  • Hitch pin is sold separately
  • 1 Year Manufacturer's Warranty

Warning and Usage Guidelines

  • Cargo Carrier Carrying Capacity: The UCC500 carrier is designed to safely carry 500 lbs
  • Hitch Weigh Limit: Most Class III hitches are rated for 500 lbs Most Class IV hitches are rated for 1,000 lbs
  • Vehicle Hauling Capacity: Your hauling weight may be limited by your vehicle's capacity to carry a load
  • Will not work with class II or smaller receivers
  • Some vehicles may require air shocks or heavier springs to stiffen up the suspension to prevent sagging
  • Please check with your dealer to find out your vehicle's carrying capacity
  • Not for use with 1-1/4" hitches
  • NOT recommended for use with hitch adapters / extensions

Documents

Instruction Manual

Review Summary (Based on 2 Reviews)

Reviews

4 Stars Good ramp

Jim from NJ wrote (November 24, 2014):

The ramp is a solid ramp. It can support a large snow blower. Centering the snow blower is needed or it will tilt to the heavier side.

4 Stars Hitch mounted cargo carrier

Dan from NH wrote (October 14, 2014):

After a few years of getting big snowblowers and other items up into a high bed F250HD I decided to try a hitch mount carrier, I have always been skeptical after seeing the small size and lightweight construction of the ones in local autoparts stores.Discount ramp offered the correct width and I took the chance. I was not disappointed! This unit is a solid, easy to assemble and well designed. I have put the equipment on and off as trial runs for winter and am very pleased with the product.
