Race Ramps™ 5" H Lip Nose Rack Ramps for Service Platform with Removable Ramps - 6,000 lb. GVW Capacity per Pair

$427.27
ITEM #RR-RACK-5
Free Shipping
In Stock, Ships from Wisconsin. Delivered in 3-5 Business Days

Key Features:

  • Lifts a car up 5" for access to service platforms or lifts; prevents damage to low-profile vehicles with 8.6° approach angle
  • Ramps measure 40" L x 14" W x 5" H and support 6,000 lb. GVW
  • Works with most industry four-post lift systems

See More…

Overview
Specifications
Made in the USA
Maximum Capacity:
1,500 lbs.
Weight:
9 lbs.
Length:
40"
Width:
14"
Height:
5"
Maximum Tire Width:
12"
Approach Angle Degree:
8.6°
Connector:
3" bridge
Material:
Foam
Color:
Black
Sold As:
Pair
More Information

The Race Ramp Solid Rack Ramps are designed to be used with service platforms or lifts to prevent damage to the front end of low-profile vehicles during loading by easing the incline from ground to platform. These car ramps are made from durable and lightweight high-density, expanded foam with high-traction coating, which will not damage your garage or cement floor. Each rack ramp weighs 9 lbs., and can support up to 1,500 lbs. for a total vehicle weight capacity of 6,000 lbs. From the ground to the underside of the ramp lip measures 5 inches, and the ground to the top of the ramp lip measures 5.5 inches.

These ramps are manufactured using an exclusive, patented process. They are constructed of 100% solid, high-density foam with a rugged anti-slip coating that results in a lightweight ramp solution that is strong, yet durable.

  • Lifts a car up 5" for access to service platforms or lifts; prevents damage to low-profile vehicles with 8.6° approach angle
  • Ramps measure 40" L x 14" W x 5" H and support 6,000 lb. GVW
  • Works with most industry four-post lift systems
  • Accommodates tires up to 12" W
  • Lightweight and portable for quick set up, removal and storage
  • Sold in pairs
  • Manufactured in the USA from 100% solid, high-density foam with a rugged anti-slip coating
Usage Guidelines
Before using the ramps ensure other persons are clear of the vehicle and the ramps. Ensure that the ramps are free from damage or corrosion before use. Use only a single pair of wheel ramps at the front or rear, do not use two ramps on one side of the vehicle. Position the ramps in line with the wheels, with the steering wheel pointed straight and the incline against the tire tread. Carefully drive the vehicle onto the automotive ramps until it is in the correct position. Turn the engine off, apply the parking brake, get out of the vehicle and securely chock the remaining wheels on the ground. Before starting work, walk around the vehicle ensuring it is securely positioned. Always use jack stand if a person will be going under the vehicle. On completion of the work, check the parking brake is still firmly on and remove the chocks. It is important to drive very slowly when coming off the ramps to prevent the automotive bodywork from making contact with the car ramp. Exercise caution when using these car ramps with a trailer or three wheeled vehicles.
Race Ramps Instruction Manual
WARNING: This product can expose you to chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
