Black Widow Extra Wide Pneumatic ATV Lift Table - 1,000 lbs. Capacity

$1,549.99
ITEM #BW-1000A-XW-ATV
In Stock, Ready to Ship
Delivered in 3 to 5 Business Days

Key Features:

  • Manufactured from heavy-duty black powder-coated steel
  • 1,000 lbs. lifting capacity
  • 78-3/4"L x 44"W table

See More…

Overview
Specifications
Length:
78-3/4"
Width:
44"
Height:
33"
Minimum Lift Height:
8"
Maximum Lift Height:
33"
Ramp Length:
25-5/8"
Maximum Capacity:
1,000 lbs.
Weight:
370 lbs.
Lift Type:
Pneumatic Compressed Air
Wheel Clamp:
Included
Rear Service Drop-Out Panel:
Yes
Side Extensions Available:
Included
Built-In Wheels:
Yes
Center Jack:
Included
Material:
Steel
More Information

Easily raise your ATV up to 33" off the ground with the Black Widow Extra-Wide Pneumatic ATV Lift Table. Featuring an ATV jack for lifting the front or rear of an ATV in seconds, this 1,000 lbs. capacity lift table is ideal for assisting with hassle-free maintenance, routine oil changes, and off-season storage at your own garage or shop. Complete with an included ATV jack that allows you to easily lift the front or rear of your ATV in seconds, this ATV lift table is easy and safe enough to use for ATV repair hobbyists of any skill level. A 21-5/8" long loading ramp makes it easy to get your ATV onto the lifting platform, and an optional wheel clamp is included for alternative use with motorcycles. Once your ATV is secured, a pneumatic foot pedal lifts the table up to 33" above the ground, and the adjustable five-position safety lock secures it in place. The stand moves effortlessly thanks to the included dolly and front wheels. The included ATV lift jack has a lifting capacity of 1,100 lbs. to accommodate almost any type of ATV, and features a 3-3/4" to 16-1/4" height range with an additional 2" to 3-1/4" using the included removable adapters.

  • Manufactured from heavy-duty black powder-coated steel
  • 1,000 lbs. lifting capacity
  • 78-3/4"L x 44"W table
  • 8" to 33" lift height
  • Rear drop out panel for servicing motorcycle tires
  • Removable 25-5/8" long rear drive-on loading ramp and ATV jack
Black Widow

This product is backed by a One Year Warranty.

Lift Table Instruction Manual Side Extension Instruction Manual
WARNING: This product can expose you to chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.

American-made lift for tune-ups, service and complete builds

Dimensions
86" or 90" L x 30" W Platform
7.5" - 40" H
For
ATVs
UTVs
Weight
1,000 lb. Capacity
Weighs approx. 370 lbs.
Features
Rear drop-out, safety locks
Compressed air operation
